Project Details

Size: 40'x40' (indicating the overall footprint of the temple).

Gargh Grah: -1 (This likely refers to the Garbhagriha or sanctum sanctorum, the innermost shrine of the temple where the main deity is housed. The "-1" might indicate one such area.)

Mandap: -1 (This refers to a Mandap or hall, typically in front of the Garbhagriha, used for various religious ceremonies or by devotees.)

Sabha Mandap: -2 (This indicates two "Sabha Mandaps" or assembly halls, larger spaces for gatherings.)

2D Floor Plan

Overall Layout: The plan shows a square-shaped structure with the dimensions clearly marked as 40' on both sides.
Garbh Grah: Located at the rear (top in the plan) and centrally positioned, highlighted in yellow. This is the most sacred part of the temple.
Mandap: Directly in front of the Garbh Grah, indicated as a single larger hall.
Sabha Mandap: Two Sabha Mandaps are shown flanking the central Mandap, suggesting a more expansive congregational space.
Entrances/Exits: Stairs are visible leading up to the main entrance area, which appears to be on the front (bottom in the plan).
Pillars/Supports: The red squares around the perimeter and within the structure likely represent columns or load-bearing elements.
